Name: BS EN 13823 Single Burning Item (SBI) Fire Performance Test Apparatus
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYF005
Price: 4,905.00 USD
Availability: InStock

घर > उत्पादों > भवन निर्माण सामग्री आग परीक्षक >

BS EN 13823 Single Burning Item (SBI) Fire Performance Test Apparatus

SBI fire test apparatus

EN 13823 fire performance tester

building material fire testing equipment

उत्पत्ति के प्लेस:

चीन

ब्रांड नाम:

YUYANG

प्रमाणन:

GBT20284, BS EN 13823

मॉडल संख्या:

YYF005

हमसे संपर्क करें

एक उद्धरण की विनती करे

BS EN 13823 Single Burning Item (SBI) Fire Performance Test Apparatus

उत्पाद का विवरण

आइटम नाम:

बीएस एन 13823 निर्माण सामग्री के लिए एकल जलने वाली वस्तु परीक्षण उपकरण (एसबीआई)

लागू होने लायक मानक:

जीबी/टी 20284-2006, आईएसओ 5725-1(2):1994, जीबी/टी 16839.1, जीबी/टी 6379.1-2004, जीबी/टी 6379.2-2004,

दहन कक्ष:

आग प्रतिरोधी इन्सुलेशन दीवारों के साथ एकीकृत फ्रेम

मुख्य बर्नर प्रकार:

स्वचालित इलेक्ट्रॉनिक इग्निशन के साथ सैंड-बॉक्स बर्नर

गैस विश्लेषण प्रणाली:

उच्च परिशुद्धता O2 और CO2 एकाग्रता माप

हीट रिलीज़ रेंज:

0 किलोवाट से 300 किलोवाट (सटीकता: ± 5%)

नियंत्रण प्रणाली:

पीसी-आधारित स्वचालित नियंत्रण

ट्रॉली प्रणाली:

आसान नमूना लोडिंग के लिए स्थिर और चल ट्रॉली

प्रमुखता देना:

SBI fire test apparatus

EN 13823 fire performance tester

building material fire testing equipment

भुगतान और शिपिंग की शर्तें

न्यूनतम आदेश मात्रा

1 सेट

मूल्य

negotiable

पैकेजिंग विवरण

परतदार लकड़ी वाला बॉक्स

प्रसव के समय

35 काम के दिन

भुगतान शर्तें

टी/टी, एल/सी, वेस्टर्न यूनियन

आपूर्ति की क्षमता

प्रति तिमाही 3 सेट

संबंधित उत्पाद

Lab UL723 ASTM E84 Building Materials Surface Burning Characteristics Testing Equipment

सबसे अच्छी कीमत पाएं

ISO-Certified Ignitability Test Apparatus for Building Materials

सबसे अच्छी कीमत पाएं

वीडियो

निर्माण सामग्री दहन विश्लेषक आईएसओ 1182 गैर-ज्वलनशीलता परीक्षण उपकरण

सबसे अच्छी कीमत पाएं

BSS 7239 लार्ज डबल-लेयर हीट-रेसिस्टेंट ग्लास स्मोक डेंसिटी टेस्ट चैंबर

सबसे अच्छी कीमत पाएं

हमसे संपर्क करें

+86-13825723571

sales002@yuyangtest.com

86-769-26622869

अब संपर्क करें

उत्पाद का वर्णन

BS EN 13823 Single Burning Item (SBI) Fire Performance Test Apparatus

Introduction

The Single Burning Item (SBI) is a test method for determining the reaction to fire behavior of building products (excluding floorings) when exposed to thermal attack by a single burning item (a sand-box burner supplied with propane). The specimen is mounted on a trolley positioned in a frame beneath an exhaust system. The specimen's reaction to the burner is monitored instrumentally and visually, with heat and smoke release rates measured instrumentally and physical characteristics assessed by observation.

Application

The Single Burning Item Test Apparatus is suitable for evaluating the fire performance of flat building products. This single combustion test method (SBI) is used for walls and roofing products.

Standards Compliance

GBT20284
EN 13823: Reaction to fire tests for building products - Building products excluding floorings exposed to the thermal attack by a single burning item
BS EN 13823: Reaction to fire tests for building products - Building products excluding floorings exposed to the thermal attack by a single burning item

Key Features

Consists of trolley, fixed frame, gas collecting hood, collector, J type exhaust pipe, centrifugal fan, wind speed control device, comprehensive measurement section, gas analysis cabinet, and data acquisition system
Trolley installs two vertical sample specimens with sand box burner at bottom vertical angle, using surface ignition method with flame detection system as flameout protection
Fixed frame supports gas collecting hood with auxiliary burner and flame detecting system
Stainless steel gas collector located at top of fixed frame for collecting combustion gases
Stainless steel J type smoke exhaust pipe with 315±5mm inner diameter and 50mm high temperature resistant mineral cotton insulation
Smoke exhaust system continuously exhausts smoke at 0.50-0.65 m³/s, regulated by frequency conversion
Mass flow controller with 0-2.5g/s measuring range and ≥1.5% reading accuracy
Automatic gas supply control for 647mg/s and 2000mg/s flow rates with ≤5mg/s variation, ensuring 30.7±2kW heat output
Flue gas sampling system with ash filter, cold trap, two drying columns, sampling pump, and peristaltic pump for clean, dry sample gas
Paramagnetic oxygen analyzer (0-25% range, T90<12 seconds) and non-dispersive infrared CO2 analyzer (0-10% range)
2155mm pipeline with pressure probe, three thermocouples, gas sampling probe, and white light system
Two-way probe with ≥0-100Pa range and 2Pa accuracy pressure sensor (90% output response ≤1s)
Incandescent light system with 2900±100K color temperature and flexible joint on exhaust pipe side
Silicon photodiode detector with 0.1% linear stability
Compressed air system for optical device cleanliness maintenance

Operating Principle

The sample consists of two vertically erected specimens intersecting at right angles and exposed to the flame of the main burner below the bottom corner. The flame, obtained by propane gas combustion through a sandbox, has a heat output of 30.7±2.0 kW.

Sample performance is evaluated within 20 minutes after ignition, measuring heat, smoke, horizontal flame spread, and burning drip/particles. Before main burner ignition, heat output is measured briefly using an identical auxiliary burner away from the sample.

Measurements include ambient temperature, flue gas temperature, humidity (observed), and automated measurements of pressure differentials, exhaust pipe temperature, gas flow, and light attenuation. These values are automatically recorded to calculate FIGRA, THR600, SMOGRA, and TSP600 parameters.

Operating Conditions

Parameter	Specification
Power Supply	AC 220V 50HZ
Power	8.5KW
Ambient Temperature	5-35°C
Relative Humidity	20-80%
Atmospheric Pressure	0-250KPa
